Roland SPD-S Technical Specifications
SPD-S Sampling Pad
PADS
Built-in Pads: 9
MAXIMUM POLYPHONY
8 voices
SAMPLING MODE
Fine/Standard/Long
SAMPLING FREQUENCY
44.1 kHz
INPUT LEVEL
Line: -10 dBu
Mic: -50 dBu
INPUT IMPEDANCE
10 k ohm (Line/Mic)
OUTPUT LEVEL
Output: -10 dBu
OUTPUT IMPEDANCE
Output: 1 k ohm
Headphones: 47 ohm
* 0 dBu = 0.775 Vrms
MEMORY
Patches: 128
Waves
Internal: 399 (Pre-loaded Sound 181)
Card: 500
MAXIMUM SAMPLING TIME
12 min. approx. (Internal Memory, Long Mode)
EFFECTS
Multi-Effects (30 types) + Ambience (System)
DISPLAY
16 characters, 1 line (backlit LCD)
CONNECTORS
Output Jacks (L/Mono, R)(1/4 inch phone type)
Input Jacks (L/Mono, R)(1/4 inch phone type)
* Line/Mic selectable
Headphones Jack (Stereo)(Stereo 1/4 inch phone type)
Trigger Input Jack (1/4 inch TRS phone type)
Expression Pedal (1/4 inch TRS phone type)
MIDI Connectors (IN, OUT)
Foot Switch Jack (1/4 iinch TRS phone type)
CompactFlash Card Slot
POWER SUPPLY
DC 9 V: AC Adaptor
CURRENT DRAW
1000 mA
DIMENSIONS
342(W) x 285(D) x 83(H) mm
13-1/2(W) x 11-1/8(D) x 3-5/16(H) inches
WEIGHT
2.1 kg
4 lbs 11 oz (excluding AC adaptor)
ACCESSORIES
Owner’s Manual
AC Adaptor (ACI-120C/ACI-230C/ACB-230E/ACB-240A)
Sampling CD
Slit Tape
Security Screw x 2
Hexagon Wrench
OPTIONS
Pads (PD-120, PD-100, PD-80, PD-80R, PD-9, PD-8, PD-7, PD-6, PDX-8, KD-7, KD-8, KD-120, KD-85)
Expression Pedal (EV-5)
Foot Switch (BOSS FS-5U)
Hi-Hat Control Pedal (FD-7/8)
PCS Connecting Cord Set (PCS-31)
All Purpose Clamp Set (APC-33)
* In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice.
