Great River EQ-1NV 1-channel EQ Module

Classic Vintage Sound with Modern Fidelity!

This article was Written By

Our Product Research Team

Get to know them!

EQ-1NV continues Great River's string of producing EQs and mic preamps that put modern spins on "Neve-esque" designs. The EQ-1NV, though based on a classic, vintage design, is built with features that allow it to seamlessly integrate into the world of DAWs. The inclusion of the 1/4" TRS -10dBv output provides zero latency monitoring for DAW users. The EQ-1NV brings the classic, warm sounds of vintage units into a box that easily situates itself easily into any live or studio rig where fidelity is of utmost concern.

Related Videos: EQ-1NV 1-channel EQ Module

• Modern Spin on the British Classic
• Flexible I/O for Stage and Studio

The EQ-1NV (one channel equalizer) greatly modernizes the classic British "1081/1083"-type design. This "desktop" (and rackable) digitally controlled analog parametric EQ offers similar topology to vintage 1081/1083 models, but with welcome improvements. Newly designed Class-A discrete single-ended amplifiers and true inductor/capacitor (L/C) circuitry add greater clarity and dynamic range to the musicality of the vintage-era models. The EQ-1NV also has a unique discrete high-current Class-A balanced output stage.

To make life in the studio (and on the road) easier, the EQ-1NV has been specifically designed to integrate with the patch loop in Great River NV Series microphone preamplifiers (with a single TRS 1/4" cable), for complete flexibility in tracking and mixing. The front panel input selector / sensitivity switch offers the option of using the signal from the EQ-1NV's transformer-coupled line input (ranging from +8dbm to -20dbm), or the patched signal from the NV preamp. When connected via the patch loop, the four EQ sections are inserted between the microphone (or DI) input's first gain stage (with level control and metering) and the preamplifier's output gain stage and "big iron" transformer (also with level control and metering). This routing flexibility provides a broad range of sonic/harmonic possibilities and maintains a full Class-A signal path.

• One channel, discrete Class-A design
• Multiple In/Out connections: XLR balanced line in and out;
• 1/4" -10dbV output for 'no-latency' DAW monitoring; TRS
• 1/4" insert patch point for NV Series mic preamp (inserts EQ between NV preamp gain stages)
• Wide range of input sensitivity from +8dbm to -20dbm with selection between line in and insert patch point
• 4 bands independently enabled with +/-15db boost/cut
• 1,2,3, or 4 bands can be used simultaneously
• Hi and low bands selectable between peaking and shelving
• Hi-mid and low-mid bands each have 3 selectable Q positions
• 3rd order selectable frequency highpass filter
• Hardwire bypass of equalizer section
• Internal low-noise shielded power supply (externally selectable for 110 / 220 volt; 50 / 60Hz)
• 3 year warranty with registration
