Lots of Control From This Compact, Affordable Mixer!
The SPLITMix4 is a 4-channel passive mixer that's equipped with four stereo input channels and one stereo output, all on 1/4" connectors. You can mix four stereo input channels down to one stereo output, split a stereo input channel to four stereo output channels, or combine these configurations to meet nearly any need. The SPLITMix4's independent stereo level controls provide over 90dB of attenuation per channel. Designed primarily as a line-level mixer for medium input/output impedances, the SPLITMix4 features a compact desktop-ready format.
Related Videos: SPLITMix4 Passive 4-channel Mixer / Splitter
- Gives you a wide range of options
- Fully passive, so it won't add noise or distortion
Gives you a wide range of options
The SPLITMix4 is a fully passive hybrid mixer that offers a wide variety of configurations. Mix 4 stereo input channels down to 1 stereo output, split a stereo input signal to distribute 4 stereo output channels, or combine the configurations for a wide range of applications. You can even configure the SPLITMix4 as 4 stereo input channels thru 4 independent level attenuators to 4 stereo output channels.
Fully passive, so it won't add noise or distortion
The fully passive design of the SPLITMix4 has no active circuitry to add noise or distortion, and virtually any signal level can be handled. The Level attenuators cover a wide range and offer over 90dB of attenuation and channel isolation.
- 100% passive design
- Four stereo input channels and one stereo output on 1/4" TRS
- Independent stereo level controls on each channel
- Offers over 90dB of attenuation
- Frequency Response: 20Hz-20kHz, +/-1dB
- THD: <0.005% at 1kHz (typical)
- Phase Response: <10 degrees at 20kHz
- Input/Output Connections: 1/4-inch TRS stereo
- Input Impedance: 25k -100k Ohms
- Output Impedance: 1k — 4k Ohms
- Insertion Loss: 12dB (typical)
- Maximum Attenuation: >90dB (typical)
- Channel Isolation: >90dB (typical)
- Power Requirements: None (fully passive)
- Dimensions (HxWxD in) : 1.85 x 4.6 x 4.1
- Dimensions (HxWxD mm) : 47 x 117 x 104
- Weight: 0.84 lbs.
