Bigger, Better Batten Displays
Springboarding from the blueprints of Elation’s original SixBar 1000, the high-powered SIX+ BAR L achieves remarkable expressiveness by utilizing next-generation LED color technology to transform everything you know about batten performance. A dozen 20-watt RGBLA+UV LEDs across the 39.4-inch-long Six+ Bar L enable myriad color mixing possibilities with stunning delivery, packing in CMY emulation, a virtual gel library, and remarkable color temperature adjustment. In addition to offering command of dimming and strobing, plus full pixel control, the Six+ Bar L comes fitted for controlling versatility across a variety of mediums, including DMX, Aria x2, and RDM. To round out the Six+ Bar L’s professional-grade componentry, rugged and C4-M marine-grade coating grants this batten a durable IP65 rating for usage in virtually any environment. For wash lighting, uplighting, accent lighting, direct view pixel strip lighting, and beyond, the Six+ Bar L is the tough, compatible, and creatively versatile batten solution you’ve been waiting for!
High-powered and vibrantly versatile
The SIX+ BAR L shines its light via 12 x 20-watt RGBLA+UV LEDs with CMY emulation built-in, coming rated for 30,000 hours of top-tier performance. You’ve got 9,325 lumens of brightness on your side as well, backed by 92.3 CRI and an incredibly wide color temperature adjustment range of 2,400K to 8,500K for crafting productions of virtually any intensity for the space and show at hand. With full pixel control, a virtual gel swatch book, and 16-bit dimming with variable curves to choose from, the Six+ Bar L makes configuring a captivatingly colorful display an incredibly manageable process. Plus, you’ll receive a frost filter, as well as a glare shield to optimize wall wash performance.
Flexible compatibility
No matter the system that you’re working with, Sweetwater lightboard experts are certain that the Six+ Bar L will make itself right at home with a diverse range of controlling options. With 15 DMX channel modes ranging from one channel to 72 channels, in addition to five SixBar 1000 Emulation DMX channel modes, this batten keeps your ecosystem’s options for synchronization wide open. Aside from DMX, you’ll find that RDM, Art-Net, sACN, KlingNet, and Aria x2 wired device management protocols are compatible controlling mediums for the Six+ Bar L. Topping it all off is a built-in LED display with a 4-button control panel, making setup and navigation of this batten’s many features completely comprehensive.
Hardy housing to match
When it comes to combining multiple units, the Six+ Bar L features end-to-end connectivity with L-track mounts on three of its sides for maximum mounting versatility. Its housing is remarkably rugged as well, earning an IP65 rating that certifies it for flawless indoor and outdoor usage. Its C4-M coating offers anti-weathering protection that even stands up to the corrosion of coastal climates! To sweeten matters, the SIX+ BAR L utilizes a fan-less convection cooling system, rounding out its professional performance with silent operation that won’t cause distractions throughout the show.
Elation Six+ Bar L Features:
- Powerful 39.4-in. batten fixture for lighting applications like washes, uplighting, accent lighting, direct view pixel strip lighting, and more
- 12 x 20W RGBLA+UV LEDs with CMY emulation offers 9,325LU of brightness, 92.3 CRI, and 2,400K–8,500K color temperature range
- Full pixel control, virtual gel swatch book, and 16-bit dimming with variable curves extend your creative freedom
- Frost filter and glare shield are included with the SIX+ BAR L
- Control with 15 DMX channel modes, 5 SixBar 1000 Emulation DMX channel modes, RDM, Art-Net, sACN, KlingNet, and Aria x2 protocols
- LED display with a 4-button control panel makes configuration a breeze
- End-to-end connectivity and 3-sided L-track mounting provided
- IP65 rating with C4-M coating is perfect for indoor/outdoor usage, even amid coastal climates
- Fan-less convection cooling system supplies noise-free operation
